Wire Rods

We at Prime Steel manufacture various types of grades in wire rods, such as low carbon, cold heading (CHQ), medium carbon, high carbon, and other alloy grades that include free-cutting steel, ball-bearing steel, and any other grades required by our customers.

These wire rods can be used in multiple engineering industries such as hand tools, automotive, cycles, fasteners, cables, nails, screws, etc. We offer wire rods in sizes ranging from 5.5 mm to 32 mm.

Resources & Specifications

Dimensional Tolerance

Size (mm):

5.5, 6, 8, 9, 10, 11.50, 12, 13, 14, 15, 16, 17, 18, 20, 23, 24, 28, 32

Tolerance (mm):

+/- 0.20


Grades

Low carbon grades :

SAE 1006 / 1008 / 1010 / 1012 / 1015 / 1018 / 1020, ST52’3

Medium carbon grades :

SAE1030 / 1035 / 1038 / 1040 / 1541 / EN8D

High Carbon :

C-60, C-65, C-70, C-75, C-80, C-85, C-90

Cold heading quality :

SAE1010 / 1015 / 1018 / 1020, SAE10B21, SAE15B25, SAE15B41, 19MnB4, 19B41

Free cutting grades :

EN 1A, EN 8M, EN 15AM

Ball bearing grades :

EN31, SAE52100

Alloy grades :

16MnCr5, 20MnCr5, SCM 415H, SCM 420H, SAE8620, SAE4135, SAE4140, EN19, EN24
